Development Motor: Cmy - Ricoh D037 Service Manual

Do not remove the PCDUs when you replace the drum motor-CMY.
1. Rear cover ( Section: Rear Cover)
2. Rear lower cover (
3. Open the controller box (
4. Drum motor: CMY [A] (

4.10.6 DEVELOPMENT MOTOR: CMY

1. Rear cover ( Section: Rear Cover
2. Rear lower cover (
3. Open the controller box. (
4. Development motor: CMY [A] (
4.10.7 DRUM/DEVELOPMENT MOTOR: K
1. Rear cover ( Section: Rear Cover)
1. Rear lower cover (
2. Open the controller box. (
SM
Section: Rear Lower Cover)
Section: Controller Box)
x 3, x 1)
Section: Rear Lower Cover)
Section: Controller Box)
x 3, x 1)
Section: Rear Lower Cover)
Section: Controller Box)
4-77
Drive Unit
D037/D038/D040/D041
