Ricoh D037 Service Manual page 873

5803 42 Vertical Transport 1 Sn
5803 43 Vertical Transport 2 Sn
5803 44 Tray1 Size Detection SW
5803 45 Tray2 Size Detection SW
5803 46 Bypass Size Detection SW
5803 47 Bypass Length Detection Sn
5803 48 Bypass HP Sensor
5803 49 Tray1 Paper End Sensor
5803 50 Tray2 Paper End Sensor
5803 51 Bypass Paper End Sensor
5803 52 Tray1 Set SW
5803 53 Tray2 Set SW
5803 54 Interlock SW 1
5803 55 Interlock SW 2
5803 56 DIP SW
5803 57 BCU Version
5803 58 PCU T-Collect Motor Set
5803 59 Reserve Fan:LOCK
5803 70 R-Tray Paper Exit Sensor
5803 71 R-Tray Set Sensor
5803 72 1-Bin:Transport Sensor
5803 73 1-Bin:Paper Sensor
SM Appendix
Paper detected
Paper detected
See "Table 1" below.
See "Table 1" below.
See "Table 2" below.
Not detect
Not HP
Not end
Not end
Not end
Set
Set
Door close
Door close
-
-
Not set
Lock
Paper detected
Set
Paper detected
Paper detected
9-339
System Service Mode
No paper detected
No paper detected
Detected
HP
End
End
End
Not set
Not set
Door open
Door open
-
-
Set
Normal
No paper
detected
Not set
No paper
detected
No paper
D037/D038/D040/D041
