4806 [Carriage Move]
001 -
4807 [SBU Test Pattern Change]
001 -
4808 [Factory Setting Input]
002 Execution Flag
[ACC Data Display]
This SP outputs the final data read at the end of ACC execution.
4902
A zero is returned if there was an error reading the data.
[0 to 255 / 0 / 1 /step]
001 R DATA1
002 G DATA1
003 B DATA1
004 R DATA2
005 G DATA2
006 B DATA2
4904 [IPU Board Test]
001
Test1
SM Appendix
Moves the carriage from the scanner home
position.
- Dust may fall through the DF exposure
glass. Therefore, do this SP when you
transport the machine a long distance.
-
[0 to 255 / 0 / 1 /step]
-
[0 or 1 / 0 / 1 /step]
*ENG Photo C Patch Level 1 (8-bit)
*ENG Photo M Patch Level 1 (8-bit)
*ENG Photo Y Patch Level 1 (8-bit)
*ENG Photo C Patch Level 17 (8-bit)
*ENG Photo M Patch Level 17(8-bit)
*ENG Photo Y Patch Level 17 (8-bit)
- Bit0: TAURUS register
9-183
