SC Tables
No. Type
790 D
793 B
No. Type
791 D
794 B
No. Type
792 D
D037/D038/D040/D041
Details (Symptom, Possible Cause, Troubleshooting Procedures)
Front jogger motor error without side tray (D038/D041)
Front jogger motor error with side tray (D038/D041)
The machine does not detect a correct signal from the front jogger
fence HP sensor at power-on. The 1st detection failure issues a
jam error, and the 2nd failure issues this SC code.
Defective front jogger motor
Loosen connection
Motor overload
Defective front jogger fence HP sensor
1. Replace the front jogger fence HP sensor.
2. Replace the front jogger motor.
Details (Symptom, Possible Cause, Troubleshooting Procedures)
Rear jogger motor error without side tray (D038/D041)
Rear jogger motor error with side tray (D038/D041)
The machine does not detect a correct signal from the rear jogger
fence HP sensor at power-on. The 1st detection failure issues a
jam error, and the 2nd failure issues this SC code.
Defective rear jogger motor
Loosen connection
Motor overload
Defective rear jogger fence HP sensor
1. Replace the rear jogger fence HP sensor.
2. Replace the rear jogger motor.
Details (Symptom, Possible Cause, Troubleshooting Procedures)
Pick-up roller contact motor error without side tray (D038/D041)
