Overview
7. Paper exit roller
8. Junction gate
9. Duplex unit
10. Fusing unit
11. PTR (Paper transfer roller) unit
12. Registration roller
13. Vertical transport roller 1
14. By-pass feed roller
15. Feed roller: T1

2.1.2 PAPER PATH

With options

1. DF path
2. Exit path: Straight feed out
D037/D038/D040/D041
22. Drum unit
23. Development unit
24. ITB cleaning unit
25. ITB roller
26. Toner bottle
27. ITB (Image Transfer Belt) unit
28. Inner Tray
6. By-pass tray path
7. Vertical transport path: Tray 2
2-2 SM Appendix
