005 Color Selection
006 Density: Bk
007 Density: C
008 Density: M
009 Density: Y
2111 [Line Pos. Ajust]
001 Execute: Mode a
002 Execute:Mode b
003 Execute:Mode c
SM Appendix
17: Band (Horizontal)
18: Band (Vertical)
19: Checker Flag Pattern
20: Grayscale Vertical Margin
21: Grayscale Horizontal Margin
23: Full Dot Pattern
Specifies the color for the test pattern.
[1 to 4 / 1 / 1/step]
-
1: All colors, 2: Magenta, 3: Yellow, 4:
Cyan
-
Specifies the color density for the test
pattern.
-
[0 to 15 / 15 / 1 /step]
-
0: Lightest density
15: Darkest density
-
Executes the fine line position adjustment
twice.
- If this SP is not completed (NG is
displayed), do SP2111-003 first and then try
this SP again.
Executes the fine line position adjustment
once.
-
If this SP is not completed, do SP2111-003
first and then try this SP again.
Executes the rough line position adjustment
once.
- After doing this SP, make sure to execute
SP2111-001 or -002. Otherwise, the line
position adjustment is not perfectly done.
9-33
System Service Mode
D037/D038/D040/D041
