Ricoh D037 Service Manual page 801

003 PCU: M
004 PCU: Y
005 Development Unit: Bk
006 Development Unit: C
007 Development Unit: M
008 Development Unit: Y
009 Developer: Bk
010 Developer: C
011 Developer: M
012 Developer: Y
013 ITB Unit
014 ITB Cleaning Unit
015 Fusing Unit
016 Fusing Roller
017 Fusing Belt
018 PTR Unit
019 ITB T-Collect Bottle
020 PCU T-Collect Bottle
[Coverage Range]
Sets the color coverage threshold.
Coverage rate = Coverage per page / A4 full coverage (dots) x 100
7855
There are three coverage counters: Color 1, Color 2, and Color 3
[A] 5% (default) is adjustable with SP7855-001.
[B] 20% (default) is adjustable with SP7855-002.
SM Appendix
*CTL
*CTL
*CTL
*CTL
*CTL
*CTL
*CTL
*CTL
*CTL
*CTL
*CTL
*CTL
*CTL
*CTL
*CTL
*CTL
[0 to 255 / - / 1 /step]
*CTL
*CTL
9-267
System Service Mode
D037/D038/D040/D041
