9.3 SCANNER SP MODE
9.3.1 SP1-XXX (SYSTEM AND OTHERS)
1001 [Scan Nv Version]
1001 5 -
[Compression Type]
1004
Selects the compression type for binary picture processing.
1004 1 Compression Type
[Erase margin]
Creates an erase margin for all edges of the scanned image.
1005
If the machine has scanned the edge of the original, create a margin. This SP is
activated only when the machine uses TWAIN scanning.
1005 1 Range from 0 to 5 mm
1009 [Remote scan disable]
1009 1 Enable or disable remote scan.
[Non Display Clear
1010
Light PDF]
1010 1 Enable or disable remote scan.
1011 [Org count Disp]
SM Appendix
*CTL -
[1 to 3 / 1 / 1/step ]
*CTL
1: MH, 2: MR, 3: MMR
*CTL [0 to 5 / 0 / 1 mm/step ]
[0 or 1 / 0 / - ]
*CTL
0: enable, 1: disable
[0 or 1 / 0 / - ]
*CTL
0: Display, 1: No display
[0 or 1 / 0 / - ]
*CTL
0: ON, 1: OFF
