Adjusts the side-to-side and leading registration of originals with the ARDF.
001 S-to-S Registration 1st
002 S-to-S Registration 2nd
003 Leading Edge Registration
Adjusts the amount of paper buckle to correct original skew for the front and
rear sides.
005 Buckle: Duplex: 1st
006 Buckle: Duplex: 2nd
Adjusts the erase margin at the original trailing edge.
007 Trailing Edge Erase
[ADF Input Check]
6007
Displays the signals received from the sensors and switches of the ARDF. Only
Bit 0 is used for ADF input check (
[ADF Output Check]
Activates the electrical components for functional check.
6008
It is not possible to activate more than one component at the same time (
"Output Check Table" in this section")
[ADF Free Run]
6009
Performs a DF free run in simplex, duplex mode or stamp mode.
002 Free Run Duplex Mode
[Stamp Position Adj.] Fax Stamp Position Adjustment
6010
Adjusts the horizontal position of the stamp on the scanned originals.
SM Appendix
[-3.0 to 3.0 / 0 / 0.1 mm/step ]
*ENG
[-5.0 to 5.0 / 0 / 0.1 mm/step ]
*ENG [-5.0 to 5.0 / 0 / 0.1 mm/step ]
*ENG [-5.0 to 5.0 / 0 / 0.1 mm/step ]
"Iutput Check Table" in this section").
-
