Ricoh D037 Service Manual page 583

018 ch 1: Filter: Rear: b0
019 ch 1: Filter: Rear: b1
020 ch 1: Filter: Rear: b2
021 ch 2: Filter: Front: a1
022 ch 2: Filter: Front: a2
023 ch 2: Filter: Front: b0
024 ch 2: Filter: Front: b1
025 ch 2: Filter: Front: b2
026 ch 2: Filter: Rear: a1
027 ch 2: Filter: Rear: a2
028 ch 2: Filter: Rear: b0
029 ch 2: Filter: Rear: b1
030 ch 2: Filter: Rear: b2
031 Q Format Selection
[MUSIC Threshold Setting] Line Position Adjustment: Threshold Setting DFU
2192
ch 0: ID sensor at rear, ch 1: ID sensor at center, ch 2: ID sensor at front
001 ch 0: 1st
002 ch 0: 2nd
003 ch 0: 3rd
004 ch 0: 4th
005 ch 1: 1st
006 ch 1: 2nd
007 ch 1: 3rd
SM Appendix
*ENG [–131071 to 131071 / 84 / 1 bit/step]
*ENG [–131071 to 131071 / 168 / 1 bit/step]
*ENG [–131071 to 131071 / 84 / 1 bit/step]
*ENG
[–131071 to 131071 / 125869 / 1 bit/step]
*ENG
[–131071 to 131071 / –60488 / 1 bit/step]
*ENG
[–131071 to 131071 / 39 / 1 bit/step]
*ENG [–131071 to 131071 / 77 / 1 bit/step]
*ENG [–131071 to 131071 / 39 / 1 bit/step]
*ENG [–131071 to 131071 / 128596 / 1 bit/step]
*ENG [–131071 to 131071 / –63398 / 1 bit/step]
*ENG [–131071 to 131071 / 84 / 1 bit/step]
*ENG [–131071 to 131071 / 168 / 1 bit/step]
*ENG
[–131071 to 131071 / 84 / 1 bit/step]
*ENG
[0 to 3 / 3 / 1/step]
*ENG [0.5 to 3 / 1.4 / 0.1 V/step]
*ENG
*ENG
*ENG
*ENG
*ENG
*ENG
9-49
System Service Mode
D037/D038/D040/D041
