System Service Mode

Job End: Potential

Interrupt: Potential

Interrupt: Potential

[Refresh Mode] DFU

While making prints with low coverage, the developer is agitated with less

toner consumption and the toner carrier attraction tends to increase. This may

cause low image density or poor transfer (white dots). To prevent this, the

coagulated toner or overcharged toner has to be consumed by performing the

refresh mode.

001 Dev. Motor Rotation: Display: Bk

002 Dev. Motor Rotation: Display: C

003 Dev. Motor Rotation: Display: M

004 Dev. Motor Rotation: Display: Y

005 Rotation Threshold

006 Pixel Coverage Sum: Bk

007 Pixel Coverage Sum: C

008 Pixel Coverage Sum: M

009 Pixel Coverage Sum: Y

010 Required Area: Bk

011 Required Area: C

012 Required Area: M

D037/D038/D040/D041

[0 to 2000 / 100 / 1 page/step]

[0 to 2000 / 500 / 1 page/step]

[0 to 2000 / 200 / 1 page/step]

[0 to 1000 / 0 / 0.1 m/step]

[0 to 1000 / 0.1 / 1 m/step]

[0 to 65535 / 0 / 1 cm
