Original Length Sensors - Ricoh D037 Service Manual

Scanner Unit
2. SBU cover [A] (
The three screws [B] do not need to be fully removed. Just loosen them to
remove the SBU cover.
3. Original length sensors [A] (hooks,
4.5.3 EXPOSURE LAMP
1. Rear cover ( Section: Rear Cover)
2. Operation panel (
3. Exposure glass (
D037/D038/D040/D041
x 6)
x1,
Section: Operation Panel)
Section: Exposure Glass)
x 1 each))
4-28 SM
