1.2.3 FEED BELT
1.
Open the left cover.
2.
Original feed unit (
3.
Feed belt cover [A] (spring x 1)
When reassembling the feed belt cover, make sure that the projection [B] of
the feed belt cover is on the guide plate rear [C].
4.
Belt tension unit [D]
SM
"Original Feed Unit")
3
