Ricoh D037 Service Manual page 591

[Common: BW: Bias] Image Transfer Belt: B/W: Bias Adjustment
2351
Normal: 120 mm/sec, Low: 60 mm/sec
Image Transfer:Standard Speed
001
Adjusts the current for the image transfer belt in B/W mode for plain paper.
Image Transfer:Low Speed
003
Adjusts the current for the image transfer belt in B/W mode for thick 1 paper.
[Common: FC: Bias] Image Transfer Belt: Full Color: Bias Adjustment
2357
Normal: 120 mm/sec, Low: 60 mm/sec
Image Transfer: Standard Spd:Bk
001
Adjusts the current for the image transfer belt for Black in full color mode for
plain paper.
Image Transfer:: Standard Spd:C
002
Adjusts the current for the image transfer belt for Cyan in full color mode for
plain paper.
Image Transfer: Standard Spd:M
003
Adjusts the current for the image transfer belt for Magenta in full color mode for
plain paper.
Image Transfer: Standard Spd:Y
004
Adjusts the current for the image transfer belt for Yellow in full color mode for
plain paper.
Image Transfer: Low Speed:Bk
009
Adjusts the current for the image transfer belt for Black in full color mode for
thick 1 paper.
Image Transfer: Low Speed:C
010
Adjusts the current for the image transfer belt for Cyan in full color mode for
SM Appendix
[0 to 60 / 25 / 1 μA]
*ENG
[0 to 60 / 13 / 1 μA]
*ENG
[0 to 60 / 23 / 1 μA]
*ENG
[0 to 60 / 22 / 1 μA]
*ENG
[0 to 60 / 25 / 1 μA]
*ENG
[0 to 60 / 29 / 1 μA]
*ENG
[0 to 60 / 13 / 1 μA]
*ENG
[0 to 60 / 12 / 1 μA]
*ENG
9-57
System Service Mode
D037/D038/D040/D041
