020 Paper Transfer: Low 2nd: S5
[Plain-T:Size-Env.Correct:FC]
Adjusts the size correction coefficient table for the paper transfer roller current
2414
for each paper size. SP2403 and SP2407 are multiplied by these SP values.
Normal: 120 mm/sec, Low: 60 mm/sec
001 Paper Transfer: Standard: 1st: S1
002 Paper Transfer: Standard: 2nd: S1
003 Paper Transfer: Low: 1st: S1
004 Paper Transfer: Low: 2nd: S1
005 Paper Transfer: Standard: 1st: S2
006 Paper Transfer: Standard: 2nd: S2
007 Paper Transfer: Low: 1st: S2
008 Paper Transfer: Low : 2nd:S2
009 Paper Transfer: Standard: 1st: S3
010 Paper Transfer: Standard: 2nd: S3
SM Appendix
[1 to 50 / 13 / 1/step]
150 mm ≥ S5 size (Paper
*ENG
width)
*ENG
*ENG
[1 to 50 / 30 / 1/step]
S1 size ≥ 290 mm (Paper width)
*ENG
*ENG
[1 to 50 / 37 / 1/step]
290 mm ≥ S2 size ≥ 250 mm
*ENG
(Paper width)
[1 to 50 / 16 / 1/step]
290 mm ≥ S2 size ≥ 250 mm
*ENG
(Paper width)
[1 to 50 / 32 / 1/step]
290 mm ≥ S2 size ≥ 250 mm
*ENG
(Paper width)
[1 to 50 / 24 / 1/step]
290 mm ≥ S2 size ≥ 250 mm
*ENG
(Paper width)
[1 to 50 / 36 / 1/step]
250 mm ≥ S3 size ≥ 194 mm
*ENG
(Paper width)
[1 to 50 / 9 / 1/step]
*ENG
250 mm ≥ S3 size ≥ 194 mm
9-65
System Service Mode
D037/D038/D040/D041
