4.4.13 FRONT RIGHT COVER
1.
Open the duplex unit.
1.
PCDU toner collection bottle (
1.
Inner right cover (
2.
Remove the front right cover [A] with the operation panel [B] lifted up (
4.4.14 RIGHT UPPER COVER
1.
Right upper cover [A] (
D037/D038/D040/D041
x 4)
Section: PCDU Toner Collection Bottle)
Section: Inner Right Cover)
x 2)
4-22
x 1).
