System Service Mode
017 Paper Transfer: 1st: S5
018 Paper Transfer:: 2nd: S5
[Thick-T:Size-Env.Correct:BW]
Adjusts the size correction coefficient table for the paper transfer roller current
2513
for each paper size. SP2502 and SP2507 are multiplied by these SP values.
Thick: 60 mm/sec
001 Paper Transfer: 1st: S1
002 Paper Transfer: 2nd: S1
005 Paper Transfer: 1st: S2
006 Paper Transfer: 2nd: S2
009 Paper Transfer: 1st: S3
010 Paper Transfer: 2nd: S3
013 Paper Transfer: 1st: S4
014 Paper Transfer: 2nd: S4
D037/D038/D040/D041
194 mm ≥ S4 size ≥ 150 mm
(Paper width)
[100 to 4000 / 690 / 5%/step]
*ENG
150 mm ≥ S5 size (Paper width)
[100 to 4000 / 1000 / 5%/step]
*ENG
150 mm ≥ S5 size (Paper width)
*ENG
[1 to 50 / 30 / 1/step]
S1 size ≥ 290 mm (Paper width)
*ENG
[1 to 50 / 36 / 1/step]
*ENG 290 mm ≥ S2 size ≥ 250 mm (Paper
width)
[1 to 50 / 21 / 1/step]
*ENG 290 mm ≥ S2 size ≥ 250 mm (Paper
width)
[1 to 50 / 40 / 1/step]
*ENG 250 mm ≥ S3 size ≥ 194 mm (Paper
width)
[1 to 50 / 8 / 1/step]
*ENG 250 mm ≥ S3 size ≥ 194 mm (Paper
width)
[1 to 50 / 27 / 1/step]
*ENG 194 mm ≥ S4 size ≥ 150 mm (Paper
width)
*ENG [1 to 50 / 5 / 1/step]
