No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
FGATE ON error: Y
The PFGATE ON signal does not assert within 5 seconds after
232 D
processing the image in normal job or MUSIC (line position adjustment)
for start position [Y].
See SC 230 for troubleshooting details.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
FGATE OFF error: Y
The PFGATE ON signal still asserts within 5 seconds after
processing the image in normal job or MUSIC (line position
233 D
adjustment) for end position [Y].
The PFGATE ON signal still asserts when the next job starts.
See SC 230 for troubleshooting details.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
FGATE ON error: M
The PFGATE ON signal does not assert within 5 seconds after
234 D
processing the image in normal job or MUSIC (line position adjustment)
for start position [M].
See SC 230 for troubleshooting details.
SM Appendix 4-11
SC Tables
D037/D038/D040/D041
