Image Transfer
2. Bottle full sensor assembly [A] (
3. ITB toner collection bottle full sensor [B] (hooks)

4.8.3 ITB (IMAGE TRANSFER BELT) UNIT

1. Left cover ( Section: Left Cover)
2. ITB cleaning unit (
3. PCU toner collection bottle (
4. Unlock the ITB lock lever (
5. Duplex unit ( Section: Duplex Unit)
6. Hinge bracket [A] (
7. Pull the lever [B] to open the paper transfer unit.
8. Harness cover [C] (
D037/D038/D040/D041
x 1,
Section: ITB Cleaning Unit)
Section: PCDU Toner Collection Bottle)
Section: Inner Right Cover).
x 1)
x 1)
4-60
x 1, x 1)
