Service Program Mode
2. If you need to perform a test print, press Copy Window to open the copy window and
select the settings for the test print. Press Start  and then press SP Mode
(highlighted) in the copy window to return to the SP mode display.
3. Press Exit two times to return to the copy window when you are finished.

Service Mode Lock/Unlock

At locations where the machine contains sensitive data, the customer engineer cannot
operate the machine until the Administrator turns the service mode lock off. This function
makes sure that work on the machine is always done with the permission of the
Administrator.
1. If you cannot go into the SP mode, ask the Administrator to log in with the User Tool
and then set "Service Mode Lock" to OFF after he or she logs in:
User Tools > System Settings > Administrator Tools > Service Mode Lock > OFF
This unlocks the machine and lets you get access to all the SP codes.
The CE can service the machine and turn the machine off and on. It is not
necessary to ask the Administrator to log in again each time the machine is turned
on.
2. Go into the SP mode and set SP5169 to "1" if you must use the printer bit switches.
3. After machine servicing is completed:
Change SP5169 from "1" to "0".
Turn the machine off and on. Tell the administrator that you have completed
servicing the machine.
The Administrator will then set the "Service Mode Lock" to ON.
5.1.3 TYPES OF SP MODES (D037/D040)
System SP: SP modes related to the engine functions
Printer SP: SP modes related to the controller functions
Scanner SP: SP modes related to the scanner functions
Fax SP: SP modes related to the fax functions
Select one of the Service Program modes (System, Printer, Scanner, or Fax) from the
operation panel as shown in the diagram below after you access the SP mode. This section
explains the functions of the System/Printer/Scanner SP modes. Refer to the Fax service
manual for the Fax SP modes.
D037/D038/D040/D041 5-4 SM
