Paper Feed
2.
Release the two clamps [A].
3.
Paper end sensor: T1 [B] (hooks,
Paper End Sensor: T2
1.
Paper tray 1 and 2 (
2.
Release the clamp [A].
3.
Paper end sensor: T2 [B] (hooks,
4.12.6 REGISTRATION SENSOR
1.
Duplex unit (
Section: Duplex Unit)
2.
Open the paper transfer unit to the fully-open position (
Transfer Roller) Unit).
3.
Registration roller guide [A] (
D037/D038/D040/D041
x 1)
Section: Paper Tray)
x 1)
x 2)
4-104
Section: PTR (Paper
SM
