Development Clutch: K - Ricoh D037 Service Manual

Drive Unit
3. Drum/Development motor: K [A] (

4.10.8 DEVELOPMENT CLUTCH: K

1. Rear cover ( Section: Rear Cover)
1. Rear lower cover (
2. Open the controller box. (
3. Drum/Development Motor: K (
4. Remove the bracket with the development clutch: K [A] (
5. Remove the development clutch: K [B] from the bracket.
4.10.9 FUSING/PAPER EXIT MOTOR
1. Rear cover ( Section: Rear Cover)
1. Rear lower cover (
2. Open the controller box. (
3. Drum/Development Motor: K (
D037/D038/D040/D041
x 3,
Section: Rear Lower Cover)
Section: Controller Box)
Section: Drum/Development Motor: K)
Section: Rear Lower Cover)
Section: Controller Box)
Section: Drum/Development Motor: K)
4-78
x 1)
x 2, x 1, x 1)
SM
