4.10 DRIVE UNIT

The drawing above shows the drive unit layout.
1. ITB drive motor
2. Fusing/paper exit motor
3. Drum motor: CMY
4. Development motor: CMY
5. Development clutch: K
There are some motors and clutches that are not shown in the above drawing:
Duplex inverter motor
Duplex Entrance Motor
4.10.1 GEAR UNIT
1. Rear cover ( Section: Rear Cover)
2. Rear lower cover (
SM
6. Drum/Development motor: K
7. Paper feed motor: T1
8. Paper feed motor: T2
9. Registration motor
Section: Rear Lower Cover)
4-73
Duplex Exit Motor
By-pass Motor
D037/D038/D040/D041
Drive Unit
