Ricoh D037 Service Manual page 629

005 Paper Transfer:FC:Standard:1st
006 Paper Transfer:FC:Standard:2nd
009 Paper Transfer:BW:Low:1st
010 Paper Transfer:BW:Low:2nd
011 Paper Transfer:FC:Low:1st
012 Paper Transfer:FC:Low:2nd
[SP 4: Bias: BW]
Adjusts the current for the paper transfer roller for special paper 1 in
2783
black-and-white mode.
Normal: 120 mm/sec, Low: 60 mm/sec
001 Paper Transfer: Normal: 1st
[SP 4: Bias: FC]
Adjusts the current for the paper transfer roller for special paper 1 in full color
2787
mode.
Normal: 120 mm/sec, Low: 60 mm/sec
001 Paper Transfer: Normal: 1st
[SP4,5,6-T:Size Correct:BW]
Adjusts the size correction coefficient for the paper transfer roller current for
2791
each paper size. SP2783 and SP2787 are multiplied by these SP values.
Normal: 120 mm/sec, Low: 60 mm/sec
001 Paper Transfer: Normal S1
005 Paper Transfer: Normal: S2
SM Appendix
*ENG [1 to 50 / 38 / 1-uA /step]
*ENG [1 to 50 / 33 / 1-uA /step]
*ENG [1 to 50 / 32 / 1-uA /step]
*ENG
[1 to 50 / 21 / 1-uA /step]
*ENG
[1 to 50 / 48 / 1-uA /step]
*ENG
[1 to 50 / 28 / 1-uA /step]
*ENG [0 to 200 / 15 / 1 –μA /step]
*ENG
[0 to 200 / 15 / 1 –μA /step]
[100 to 4000 / 100 / 5%/step]
*ENG
S1 size ≥ 290 mm (Paper width)
[100 to 4000 / 125 / 5%/step]
*ENG
290 mm ≥ S2 size ≥ 250 mm (Paper
9-95
System Service Mode
D037/D038/D040/D041
