Ricoh D037 Service Manual page 603

Adjusts the current for the paper transfer roller for thin paper in black-and-white
mode.
Standard: 120 mm/sec, Low: 60 mm/sec
001 Paper Transfer: Standard: 1st
003 Paper Transfer: Low: 1st
[Thin: Bias: FC]
2457
Adjusts the current for the paper transfer roller for thin paper in full color mode.
Standard: 120 mm/sec, Low: 60 mm/sec
001 Paper Transfer: Standard: 1st
003 Paper Transfer: Low: 1st
[Thin: L-Edge Correction] Thin Paper: Leading Edge Correction
Adjusts the correction to the paper transfer roller current at the paper leading
edge in each mode. SP2453 and SP2457 are multiplied by these SP values.
2471
Standard: 120 mm/sec, Low: 60 mm/sec
The paper leading edge area can be adjusted with SP2472.
001 Paper Transfer: Standard: 1st
003 Paper Transfer: Low: 1st
[Thin: Switch Timing: L-Edge]
Adjusts the bias/ voltage switch timing of the paper transfer roller/ discharge
2472
plate at the paper leading edge between the erase margin area and the image
area.
Standard: 120 mm/sec, Low: 60 mm/sec
001 Paper Transfer: Standard: 1st
003 Paper Transfer: Low: 1st
SM Appendix
*ENG
[0 to 200 / 20 / 1 –μA /step]
*ENG
[0 to 250 / 12 / 1 –μA /step]
*ENG [0 to 200 / 23 / 1 –μA /step]
*ENG [0 to 200 / 13 / 1 –μA /step]
*ENG
[0 to 400 / 100 / 5%/step]
*ENG
*ENG
[0 to 30 / 0 / 2 mm/step]
*ENG
9-69
System Service Mode
D037/D038/D040/D041
