Ricoh D037 Service Manual page 895

1101 2 Previous
1101 3 Current
1101 4 ACC
[Resolution Setting]
1102
Selects the printing mode (resolution) for the printer gamma adjustment.
2400x600 Photo, 1800x600 Photo, 600 x 600 Photo, 2400x600 Text,
1102 1
1800x600, Text, 600x600 Text
[Test Page]
1103
Prints the test page to check the color balance before and after the gamma
adjustment.
1103 1 Color Gray Scale
1103 2 Color Pattern
[Gamma Adjustment]
1104
Adjusts the printer gamma for the mode selected in the "Mode Selection"
menu.
1104 1 Black: Highlight
1104 2 Black: Shadow
1104 3 Black: Middle
1104 4 Black: IDmax
1104 21 Cyan: Highlight
1104 22 Cyan: Shadow
1104 23 Cyan: Middle
SM Appendix
*CTL [0 to 30 / 15 / 1/step ]
9-361
Printer Service Mode
D037/D038/D040/D041
