Ricoh D037 Service Manual page 627

Paper Transfer: Standard: 1st:
017
S5
Paper Transfer: Standard: 2nd:
018
S5
019 PaperTransfer:Low:1st:S5
020 PaperTransfer:Low:2nd:S5
[SP1: L-Edge Correct] Special 1 Paper: Leading Edge Correction
Adjusts the correction to the paper transfer roller current at the paper leading
edge in each mode. SP2753 and SP2757 are multiplied by these SP values.
2771
Standard: 120mm/sec, Low: 60mm/sec
The paper leading edge area can be adjusted with SP2772.
001 Paper Transfer: Standard: 1st
002 Paper Transfer: Standard: 2nd
003 Paper Transfer: Low: 1st
004 Paper Transfer: Low: 2nd
[SP 1: Switch Timing: L-Edge]
Adjusts the bias/ voltage switch timing of the paper transfer roller/ discharge
2772
plate at the paper leading edge between the erase margin area and the image
area.
Standard: 120mm/sec, Low: 60mm/sec
001 Paper Transfer: Standard: 1st
002 Paper Transfer: Standard: 2nd
003 Paper Transfer: Low: 1st
SM Appendix
[1 to 50 / 12 / 1%/step]
*ENG
150 mm ≥ S5 size (Paper width)
[1 to 50 / 7 / 1%/step]
*ENG
150 mm ≥ S5 size (Paper width)
[1 to 50 / 27 / 1%/step]
*ENG
150 mm ≥ S5 size (Paper width)
[1 to 50 / 4 / 1%/step]
*ENG
150 mm ≥ S5 size (Paper width)
*ENG
*ENG
[0 to 400 / 100 / 5%/step]
*ENG
*ENG
*ENG [0 to 30 / 0 / 2 mm/step]
*ENG
*ENG
9-93
System Service Mode
D037/D038/D040/D041
