Paper Transfer
3. ID sensor cover [A] (
4. ID sensor board [A] (
If the black spacer [B] is stuck to the sensor board as shown above, remove
all black spacers. These black spacers should be used when a new ID sensor
board is installed.

Cleaning for ID sensors

ID sensors require cleaning maintenance every EM. Do the following steps for ID sensor
cleaning.
1. PCDU: K ( Section: PCDU (Photo Conductor and Development Unit))
2. ITB unit ( Section: ITB (Image Transfer Belt) Unit)
D037/D038/D040/D041
x 2)
x 6, , x 1, x 1)
4-70 SM
