System Service Mode
Ends Temp. 4: –226
017 Specifies the temperature correction for the heating roller (ends) when the
paper width is less than 226 mm.
The start time of this SP can be adjusted with SP1116-021.
Control Time 1: 226–
Specifies the start time of the temperature correction that is set with
018
SP1116-010 and -011.
The temperature correction is added when the time specified with this SP has
passed after feeding the paper.
Control Time 2: 226–
Specifies the start time of the temperature correction that is set with
019
SP1116-012 and -013.
The temperature correction is added when the time specified with this SP has
passed after feeding the paper.
Control Time 3: –226
Specifies the start time of the temperature correction that is set with
020
SP1116-014 and -015.
The temperature correction is added when the time specified with this SP has
passed after feeding the paper.
Control Time 4: –226
Specifies the start time of the temperature correction that is set with
021
SP1116-016 and -017.
The temperature correction is added when the time specified with this SP has
passed after feeding the paper.
022 Center Temp.1:Duplex:226-
023 Ends Temp.1:Duplex:226-
024 Center Temp.2:Duplex:226-
025 Ends Temp.2:Duplex:226-
D037/D038/D040/D041
ENG [-10 to 10 / -10 / 1 deg/step]
ENG
[0 to 250 / 0 / 1 sec/step]
ENG [0 to 250 / 0 / 1 sec/step]
ENG [0 to 250 / 30 / 1 sec/step]
ENG [0 to 250 / 60 / 1 sec/step]
ENG [-10 to 10 / 0 / 1 deg/step]
ENG
ENG
ENG
9-16 SM Appendix
