System Service Mode

Displays or adjusts the current Vtref value for each color.

001 Current: Bk

002 Current: C

003 Current: M

004 Current: Y

Displays or adjusts the Vtref value for each color at developer initialization.

005 Initial: Bk

006 Initial: C

007 Initial: M

008 Initial: Y

009-012 Displays and adjusts Vtref correction by pixel coverage for each color. DFU

009 Pixel Correction: Bk

010 Pixel Correction: C

011 Pixel Correction: M

012 Pixel Correction: Y

[Vtref U/Lower: Set] DFU

Adjusts the lower or upper limit value of Vtref for each color.

001 Lower: Bk

002 Lower: C

003 Lower: M

004 Lower: Y

005 Upper: Bk

D037/D038/D040/D041

[0 to 5.5 / 3 / 0.01 V/step]

[0 to 5.5 / 3 / 0.01 V/step]

[-5 to 5.5 / 0 / 0.01 V/step]

[-5 to 5 / 0 / 0.01 V/step]

[0 to 5 / 2 / 0.01 V/step]

[0 to 5 / 4 / 0.01 V/step]
