Ricoh D037 Service Manual page 569

[P-Sensor Test]
Displays the maximum result values of the ID sensor check.
2140
Bk, M, C, Y: ID sensors for the process control
Front, Center, Rear: ID sensors for the automatic line position adjustment
001 PWM
[TM-Sensor Test] DFU
005 PWM: Front
006 PWM: Center
007 PWM: Rear
[P-Sensor Test]
Displays the maximum result values of the ID sensor check.
2141
Bk, M, C, Y: ID sensors for the process control
Front, Center, Rear: ID sensors for the automatic line position adjustment
001 Average
[TM-Sensor Test] DFU
005 Average: Front
006 Average: Center
007 Average: Rear
[P-Sensor Test] DFU
Displays the maximum result values of the ID sensor check.
2142
Bk, M, C, Y: ID sensors for the process control
Front, Center, Rear: ID sensors for the automatic line position adjustment
001 Maximum
[TM-Sensor Test] DFU
SM Appendix
*ENG
[0 to 1024 / 0 / 1/step]
*ENG
*ENG
*ENG
*ENG
[0 to 5.5 / 0 / 0.01V/step]
*ENG
*ENG
*ENG
*ENG [0 to 5.5 / 0 / 0.01V/step]
9-35
System Service Mode
D037/D038/D040/D041
