Ricoh D037 Service Manual page 610

System Service Mode
017 Paper Transfer: 1st: S5
018 Paper Transfer: 2nd: S5
[Thick 1:L-Edge Correct] Thick 1 Paper: Leading Edge Correction
Adjusts the correction to the paper transfer roller current at the paper leading
edge in each mode. SP2502 and SP2507 are multiplied by these SP values.
2521
Thick: 60 mm/sec
The paper leading edge area can be adjusted with SP2522.
001 Paper Transfer: 1st
002 Paper Transfer: 2nd
[Thick 1: Switch Timing: L-Edge]
Adjusts the bias/ voltage switch timing of the paper transfer roller/ discharge
2522
plate at the paper leading edge between the erase margin area and the image
area.
Thick: 60 mm/sec
001 Paper Transfer: 1st
002 Paper Transfer: 2nd
[Thick 1: T-Edge Correction] Thick 1 Paper: Trailing Edge Correction
Adjusts the correction coefficient to the paper transfer roller current for the
2523
paper trailing edge in each mode. SP2502 and SP2507 are multiplied by these
SP values.
Thick: 60 mm/sec
D037/D038/D040/D041
194 mm ≥ S4 size ≥ 150 mm (Paper
width)
[1 to 50 / 6 / 1/step]
*ENG
150 mm ≥ S5 size (Paper width)
[1 to 50 / 3 / 1/step]
*ENG
150 mm ≥ S5 size (Paper width)
*ENG
[0 to 400 / 100 / 5%/step]
*ENG
*ENG
[0 to 30 / 0 / 2 mm/step]
*ENG
9-76 SM Appendix
