Ricoh D037 Service Manual page 577

2181 [Line Pos. Adj. Result]
Displays the values for each correction.
"Paper Int. Mag: Subdot" indicates the magnification correction value
between two sheets of paper.
"Mag.Cor. Subdot" indicates the magnification correction value.
"M. Scan Erro." indicates the shift correction value in the main scan
direction.
"S. Scan Erro." Indicates the shift correction value in the sub scan
direction.
"M. Cor.: Dot" indicates the dot correction value in the main scan direction.
"M. Cor.: Subdot" indicates the sub dot correction value in the main scan
direction.
Bk: Black, M: Magenta, C: Cyan, Y: Yellow
001 Paper Int. Mag: Subdot: Bk *ENG
002 Mag.Cor. Subdot: Bk
003 Skew: C
004 Bent: C
005 M. Scan Shift: Left: C
006 M. Scan Shift: Center: C
007 M. Scan Shift: Right: C
008 S. Scan Shift: Left: C
009 S. Scan Shift: Center: C
010 S. Scan Shift: Right: C
011 M. Cor.: Dot: C
012 M. Cor.: Subdot: C
013 Paper Int. Mag: Subdot: C
014 Mag.Cor. Subdot: C
SM Appendix
[–32768 to 32767 / 0 / 1 pulse/step]
*ENG [–32768 to 32767 / 0 / 1 pulse/step]
*ENG
*ENG
*ENG
*ENG
[–5000 to 5000 / 0 / 0.001 um/step]
*ENG
*ENG
*ENG
*ENG
*ENG [–512 to 511 / 0 / 1 dot/step]
*ENG [–15 to 15 / 0 / 1 pulse/step]
*ENG [–32768 to 32767 / 0 / 1 pulse/step]
*ENG
9-43
System Service Mode
D037/D038/D040/D041
