Ricoh D037 Service Manual page 519

Jam Code
Display
SP
7504 24 Inverter Sn: ON
7504 25 Duplex Exit: ON
7504 27 Duplex Entrance: ON
7504 28 1-Bin Exit Sensor
7504 29 R-tray Paper Exit: ON
Vertical Transport
7504 51
Sensor1
Vertical Transport
7504 52
Sensor2
Vertical Transport
7504 53
Sensor3
7504 57 Registration Sensor
Fusing Entrance
7504 58
Sensor
7504 59 Fusing Exit Sensor
7504 60 Exit Sensor
7504 64 Inverter Sensor
7504 65 Duplex Exit Sensor
Duplex Entrance
7504 67
Sensor
7504 68 1-Bin Exit: ON
SM Appendix
Description
Inverter sensor does not detect paper.
Duplex exit sensor does not detect
paper.
Duplex entrance sensor does not detect
paper.
1-bin tray exit sensor does not detect
paper.
Paper exit sensor of the side tray does
not detect paper.
Vertical transport sensor 1 does not turn
off.
Vertical transport sensor 2 does not turn
off.
Vertical transport sensor 3 does not turn
off.
Registration sensor does not turn off.
Fusing entrance sensor does not turn
off.
Fusing exit sensor does not turn off.
Paper exit sensor does not turn off.
Inverter sensor does not turn off.
Duplex exit sensor does not turn off.
Duplex entrance sensor does not turn
off.
1-bin tray exit sensor does not turn off.
7-3
Jam Detection
LCD
Display
C
Z
Z
C
C
A1, A2
Y
Y
B
C
C
C
C
Z
Z
R
