Controller Options
transmission speed for the mode: Auto, 11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps (default:
Auto). This setting should match the distance between the closest machine or access
point. This depends on which mode is selected.
For the Ad Hoc Mode, this is the distance between the machine and the
closest PC in the network. For the Infrastructure Mode, this is the distance
between the machine and the closest access point.
11 Mbps: 140 m (153 yd.)
5.5 Mbps: 200 m (219 yd.)
2 Mbps: 270 m (295 yd.)
1 Mbps: 400 m (437 yd.)
⇒
10. This step has been removed because it was unnecessary.
SP Mode and UP Mode Settings for IEEE 802.11 a/g, g Wireless LAN
The following SP commands and UP modes can be set for IEEE 802.11 a/g, g.
SP No.
5840-006
5840-007
5840-011
UP mode
WEP Key
D037/D038/D040/D041
Name Function
Sets the maximum range of the channel settings for the
Channel MAX
country.
Sets the minimum range of the channels settings
Channel MIN
allowed for your country.
WEP Key Select Used to select the WEP key (Default: 00).
Name Function
SSID Used to confirm the current SSID setting.
Used to confirm
the current WEP
2-96
Rev. 07/01/2009
SM
