Ricoh D037 Service Manual page 657

032 Pixel: Remaining : Bk
033 Pixel: Remaining : C
034 Pixel: Remaining : M
035 Pixel: Remaining : Y
040-043 Displays the pixel M/A for each color.
040 Pixel M/A: Bk
041 Pixel M/A: C
042 Pixel M/A: M
043 Pixel M/A: Y
044 Delta Vt Threshold BF NE
Delta Vt Sum Threshold
045
BF NE
046-049 Displays the latest mohno off time.
046 Bottle Motor Off Time: Bk
047 Bottle Motor Off Time: C
048 Bottle Motor Off Time: M
049 Bottle Motor Off Time: Y
050-053
050 TE Sn Detect Thresh:Bk
051 TE Sn Detect Thresh:C
052 TE Sn Detect Thresh:M
SM Appendix
*ENG
*ENG
[-50000 to 600 / 0 / 0.001 g/step]
*ENG
*ENG
*ENG
[0 to 1 / 0.05 / 0.001 mg/cm
*ENG
*ENG
*ENG [0 to 1 / 0.6 / 0.001 mg/cm
Adjusts the delta Vt (Vt – Vtref) of toner
*ENG end before toner near end is detected.
[0 to 5 / 0.5 / 0.01 V/step]
Adjusts the total delta Vt (Vt – Vtref) of
toner end before toner near end is
*ENG
detected.
[0 to 255 / 10 / 1 V/step]
*ENG
*ENG
[0 to 0 x FFFFFFFF / 0 / 1 sec/step]
*ENG
*ENG
*ENG [1 to 600 / 33 / 1 g/step]
*ENG
*ENG
9-123
System Service Mode
2
/step]
2
/step]
D037/D038/D040/D041
