USB2.0/SD Slot Type A
7. Make four holes in the scanner left cover with a screwdriver as shown [A].
Smooth the four holes in the scanner left cover as shown [B].
8. Route the USB cable [A] through the gaps in the left scanner cover.
9. Secure the USB2.0/SD Slot [B] with the left scanner cover as shown above (
M3x8).
Use the screw holes [C] as shown above.
D037/D038/D040/D041 2-62
x 4:
