3. APPENDIX: PREVENTIVE MAINTENANCE
TABLES
3.1 MAINTENANCE TABLES
3.1.1 PREVENTIVE MAINTENANCE ITEMS
Chart: A4 (LT)/5%
Mode: 3 copies / original (prints/job)
Ratio 30%
Environment: Normal temperature and humidity
Yield may change depending on circumstances and print conditions.
Symbol keys: C: Clean, R: Replace, L: Lubricant, I: Inspect
Mainframe
Item
Scanner
Reflector
1st/2nd/3rd Mirrors
Front and Rear Rails
Exposure Glass
ADF Exposure Glass
APS Sensor
PCDU
Drum Unit-K, C, M, Y
PCDU Toner Collection Bottle
ITB and PTR unit
SM Appendix
60K 150K 240K
C
C
C
C
C
C
R
R
3-1
Maintenance Tables
EM Remarks
Optics cloth
Optics cloth
Dry cloth
C Dry cloth; alcohol
C Dry cloth; alcohol
Dry cloth
D037/D038/D040/D041
