System Service Mode

[Line Position Adj. Offset]

(Color) M. Scan: Main scan, S. Scan: Sub-scan

High / Medium: 120 mm/sec, Low: 60 mm/sec

001 C Magnification

002 M Magnification

003 Y Magnification

004 M. Scan: High: Dot: C

005 M. Scan: High: Subdot: C

008 M. Scan: Low: Dot: C

009 M. Scan: Low: Subdot: C

010 M. Scan: High: Dot: M

011 M. Scan: High: Subdot: M

014 M. Scan: Low: Dot: M

015 M. Scan: Low: Subdot: M

016 M. Scan: High: Dot: Y

017 M. Scan: High: Subdot: Y

020 M. Scan: Low: Dot: Y

021 M. Scan: Low: Subdot: Y

022 S. Scan: High: Dot: C

023 S. Scan: High: Subdot: C

026 S. Scan: Low: Dot: C

D037/D038/D040/D041

Adjusts the line position manually.

[-1 to 1 / 0 / 0.001%/step]

When line shifts are not corrected

by the automatic line position

adjustment, do this SP.

Increasing a value reduces the

image in the main scan direction.

Decreasing a value enlarges the

image in the main scan direction.

[-512 to 511 / 0 / 1 dot/step]
