Ardf (Original Jam) - Ricoh D037 Service Manual

Jam Code
Display
SP
7504 248 Belt Lift Solenoid
7504 249 Finisher Fan
7504 250 Punch Motor
7504 251 Finisher Proof Exit
FIN:Stapler Position
7504 252
Error
7504 253 FIN:Job Data Error
The jam location display depends on where a paper jam is detected at power-on.

ARDF (Original Jam)

Jam Code
Display
SP
7505 1 At Power On
7505 3 Skew Correction: ON
7505 4 Registration: ON
7505 5 Paper Exit: ON
7505 53 Skew Correction: OFF Skew correction sensor does not turn
SM Appendix
Description
The mainframe detects the belt lift
solenoid error from the internal finisher.
The mainframe detects the finisher fan
error from the internal finisher.
The mainframe detects the lock signal
from the punch motor.
The mainframe detects the lock signal
from the registration motor of the punch
unit.
The stapler unit stays on the jogger end
fence so that stapling is disabled.
Unexpected job data is sent to the
internal finisher from the mainframe.
Description
Original is stack at power-on.
Skew correction sensor does not detect
paper.
Registration sensor does not detect
paper.
Exit Sensor does not detect paper.
7-5
Jam Detection
LCD
Display
R1, R2
R1, R2
R1, R2
R1, R2
R1, R2
R1, R2
LCD
Display
P
P
P
P
P
D037/D038/D040/D041
