[SP 6: Sw Timing: L-Edge]
Adjusts the bias/ voltage switch timing of the paper transfer roller/ discharge
2896
plate at the paper leading edge between the erase margin area and the image
area.
Normal: 120 mm/sec, Low: 60 mm/sec
001 Paper Transfer
[SP6: T-Edge Correct] Special 5 Paper: Trailing Edge Correction
Adjusts the correction to the paper transfer roller current for the paper trailing
edge in each mode. SP2883 and SP2887 are multiplied by these SP values.
2897
Normal: 120 mm/sec, Low: 60 mm/sec
The paper trailing edge area can be adjusted with SP2898.
001 Paper Transfer
[SP 6: Sw Timing: T-Edge]
Adjusts the bias/voltage switch timing of the paper transfer roller/discharge
2898
plate at the paper trailing edge between the erase margin area and the image
area.
Normal: 120 mm/sec, Low: 60 mm/sec
001 Paper Transfer
2899 [SP 5: Env. Correct Table]
003 Paper Transfer:BW: 1st
005 Paper Transfer:FC: 1st
2900 [Drum Idling Time]
003 Normal Speed
SM Appendix
*ENG [0 to 30 / 0 / 2 mm/step]
*ENG [0 to 400 / 100 / 5%/step]
*ENG [0 to -100 / 0 / 2 mm/step]
*ENG [1 to 50 / 17 / 1-uA /step]
*ENG [1 to 50 / 29 / 1-uA /step]
*ENG [0 to 60 / 5 / 1sec /step]
9-107
System Service Mode
D037/D038/D040/D041
