when toner density is detected to be low at the toner density adjustment.
C-pattern: C
010
Specifies the belt mark generating time for checking the magenta toner density
when toner density is detected to be low at the toner density adjustment.
C-pattern: M
011
Specifies the belt mark generating time for checking the cyan toner density
when toner density is detected to be low at the toner density adjustment.
C-pattern: Y
012
Specifies the belt mark generating time for checking the yellow toner density
when toner density is detected to be low at the toner density adjustment.
T1 Bias: Bk
013
Adjusts the image transfer belt bias for Black.
T2 Bias: C
014
Adjusts the image transfer belt bias for Cyan.
T3 Bias: M
015
Adjusts the image transfer belt bias for Magenta.
T4 Bias: Y
016
Adjusts the image transfer belt bias for Yellow.
Developer Agitation Time
017
Specifies the developer mixing time at the toner density adjustment.
C-Pattern: LD: DUTY: Bk
Adjusts the LD duty for the toner consumption mode at the toner density
adjustment.
018
In toner consumption mode, toner is discharged when the detected
development gamma values (SP3611-001) exceed the target values
(SP3611-005) by more than the specified thresholds (SP3239-009).
SM Appendix
*ENG [0 to 255 / 5 / 1 time/step]
*ENG [0 to 255 / 5 / 1 time/step]
*ENG [0 to 255 / 5 / 1 time/step]
*ENG [0 to 80 / 10 / 1 µA/step]
*ENG [0 to 80 / 10 / 1 µA/step]
*ENG [0 to 80 / 10 / 1 µA/step]
*ENG
[0 to 80 / 10 / 1 µA/step]
*ENG
[0 to 250 / 10 / 1 sec/step]
*ENG [0 to 15 / 15 / 1 /step]
9-119
