Copier Installation
Do not remove the tape [C] at this moment. You will find how to remove this
tape later.
The toner hopper cover [D] is removed with tape [E].
Make sure that the all toner hopper covers are removed, when removing all
tapes.
3. Check if the toner hopper shutter [A] is fully closed.
If the toner hopper shutter is not fully closed and the inlet [B] of the toner
hopper unit is visible, the toner bottle cannot be installed properly.
4. Press the ITB lock lever [A] and turn it up as shown above.
5. Remove the black PCDU [B] (
D037/D038/D040/D041
x 2).
2-12 SM
