Ricoh D037 Service Manual page 633

Adjusts the bias/voltage switch timing of the paper transfer roller/discharge
plate at the paper trailing edge between the erase margin area and the image
area.
Normal: 120 mm/sec, Low: 60 mm/sec
001 Paper Transfer
2799 [SP 4: Env. Correct Table]
003 Paper Transfer:BW: 1st
005 Paper Transfer:FC: 1st
[SP 2: Bias: BW]
Adjusts the current for the paper transfer roller for special paper 2 in
2803
black-and-white mode.
Standard: 120mm/sec, Low: 60mm/sec
001 Paper Transfer: Standard: 1st
002 Paper Transfer: Standard: 2nd
003 Paper Transfer: Low: 1st
004 Paper Transfer: Low: 2nd
[SP2: Bias: FC]
Adjusts the current for the paper transfer roller for special paper 2 in full color
2807
mode.
Standard: 120mm/sec, Low: 60mm/sec
001 Paper Transfer: Standard: 1st
002 Paper Transfer: Standard: 2nd
003 Paper Transfer: Low: 1st
004 Paper Transfer: Low: 2nd
SM Appendix
*ENG [0 to -100 / 0 / 2 mm/step]
*ENG [1 to 50 / 17 / 1-uA /step]
*ENG [1 to 50 / 29 / 1-uA /step]
*ENG
[0 to 200 / 20 / 1 –μA /step]
*ENG
*ENG
[0 to 200 / 11 / 1 –μA /step]
*ENG
[0 to 200 / 13 / 1 –μA /step]
*ENG
[0 to 200 / 25 / 1 –μA /step]
*ENG
[0 to 200 / 28 / 1 –μA /step]
*ENG
[0 to 200 / 11 / 1 –μA /step]
*ENG
[0 to 200 / 14 / 1 –μA /step]
9-99
System Service Mode
D037/D038/D040/D041
