System Service Mode
document server with a print job that was stored on the document server, the C: and P:
counters both increment.
When a job already on the document server is printed with another application, the L:
counter increments.
When a scanner job stored on the document server is printed with another application,
the S: counter increments. If the original was scanned from within document server
mode, then the L: counter increments.
When images stored on the document server by a network application (including Palm
2), are printed with another application, the O: counter increments.
When a copy job stored on the document server is printed with a network application
(Web Image Monitor, for example), the C: counter increments.
When a fax on the document server is printed, the F: counter increments.
8 031 T:Pjob/DesApl
8 032 C:Pjob/DesApl
8 033 F:Pjob/DesApl
8 034 P:Pjob/DesApl
8 035 S:Pjob/DesApl
8 036 L:Pjob/DesApl
8 037 O:Pjob/DesApl
When documents already stored on the document server are printed, the count for the
application that started the print job is incremented.
When the print job is started from a network application (Desk Top Binder, Web Image
Monitor, etc.) the L: counter increments.
8 041 T:TX Jobs/LS
8 042 C:TX Jobs/LS
8 043 F:TX Jobs/LS
D037/D038/D040/D041
*CTL
These SPs reveal what applications were
*CTL
used to output documents from the
*CTL
document server.
[0 to 9999999/ 0 / 1]
*CTL
The L: counter counts the number of jobs
*CTL
printed from within the document server
mode screen at the operation panel.
*CTL
*CTL
*CTL These SPs count the applications that
stored files on the document server that
*CTL
were later accessed for transmission over
the telephone line or over a network
*CTL
