2. On the touch screen press "Touch Screen Adjust" (or press
3. Use a pointed (not sharp) tool to press the upper left mark .
4. Press the lower right mark when " " shows.
Press [#] OK on the screen (or press k) when you are finished.
5.
6. Touch [#] Exit on the screen to close the Self-Diagnostic menu. Save the calibration
settings.
4.4.11 INNER RIGHT COVER
1.

PCDU toner collection bottle (

2. Press the ITB lock lever [A] and turn it up clockwise as shown above.
3. Inner right cover [B] (
4.4.12 INNER COVER
1. PCDU toner collection bottle (
2. Inner right cover (
SM
Section: PCDU Toner Collection Bottle)
x 2)
Section: PCDU Toner Collection Bottle)
Section: Inner Cover)
4-21
Exterior Covers
).
D037/D038/D040/D041
