Installation Procedure; Tapes And Retainers - Ricoh D037 Service Manual

No.
19. CD-ROM Instruction – Network & General Setting Guide
20. CD-ROM Instruction – Security Reference
21. PostScript 3 Supplement
22. Printer Driver CD-ROM
23. Scanner Driver & Utility CD-ROM
24. Clear Cover

2.3.4 INSTALLATION PROCEDURE

Remove the tapes from the development units before you turn the main switch on.
The development units can be severely damaged if you do not remove the tapes.
Put the machine on the paper tray unit first if you install an optional paper tray unit at the
same time. Then install the machine and other options.
Keep the shipping retainers after you install the machine. You may need them in
the future if you transport the machine to another location.

Tapes and Retainers

1. Remove all the tapes and retainers on the machine.
2. Remove all the tapes and retainers in trays 1 and 2.
SM
Description
2-9
Copier Installation
Q'ty Destination
1
1
-67, -29, -21,
-19, -28
1 -29, 28
1
-57, -67, -29
1
D037/D038/D040/D041
