Troubleshooting Guide
2. Remove the interlock switch bracket [A] (
3. Loosen the four screws [A] on the front fusing guide.
4. Remove the screw [B] on the adjustor lever.
This screw is not necessary after tightening the front fusing guide.
5. If the horizontal lines slope down to the left [A], move the front fusing guide upward. To
D037/D038/D040/D041
x 3, x 1, x 2).
6-8 SM
