Ricoh D037 Service Manual page 638

System Service Mode
Adjusts the current for the paper transfer roller for special paper 3 in full color
mode.
Standard: 120mm/sec, Low: 60mm/sec
001 Paper Transfer: Standard: 1st
002 Paper Transfer: Standard: 2nd
003 Paper Transfer: Low: 1st
004 Paper Transfer: Low: 2nd
[SP 3: L-Edge Correction] Special 3 Paper: Leading Edge Correction
Adjusts the correction to the paper transfer roller current at the paper leading
edge in each mode. SP2852 and SP2857 are multiplied by these SP values.
2871
Standard: 120mm/sec, Low: 60mm/sec
The paper leading edge area can be adjusted with SP2872.
001 Paper Transfer: Standard: 1st
002 Paper Transfer: Standard: 2nd
003 Paper Transfer: Low: 1st
004 Paper Transfer: Low: 2nd
[Special 3: Switch Timing: Lead. Edge]
Adjusts the bias/ voltage switch timing of the paper transfer roller/ discharge
2872
plate at the paper leading edge between the erase margin area and the image
area.
Standard: 120mm/sec, Low: 60mm/sec
001 Paper Transfer: Standard: 1st
002 Paper Transfer: Standard: 2nd
003 Paper Transfer: Low: 1st
D037/D038/D040/D041
*ENG
[0 to 200 / 25 / 1 –μA /step]
*ENG
[0 to 200 / 28 / 1 –μA /step]
*ENG [0 to 200 / 11 / 1 –μA /step]
*ENG
[0 to 200 / 14 / 1 –μA /step]
*ENG
*ENG
[0 to 400 / 100 / 5% /step]
*ENG
*ENG
*ENG
[0 to 30 / 0 / 2 mm/step]
*ENG
*ENG
9-104 SM Appendix
