074 Rotation (%): ITB Cleaning Unit
075 Rotation (%): Fusing Unit
076 Rotation (%): Fusing Roller
077 Rotation (%): Fusing Belt
078 Rotation (%):PTR Unit
Displays the value given by the following formula:
(Current printouts ÷ Target printouts) × 100. This shows how much of the
unit's expected lifetime has been used up.
The Page% counter is based on printouts, not revolutions. If the number of
printouts reaches the limit, the machine enters the end condition for that unit.
If the revolution count lifetime is reached first, the machine also enters the
end condition, even though the Page% counter is still less than 100%.
079 Amt(%):ITB T-Collect Bottle
080 Amt(%):PCU T-Collect Bottle
[0 to 255 / - / 1 %/step]
091 Page (%): PCU: Bk
092 Page (%): PCU: C
093 Page (%): PCU: M
094 Page (%): PCU: Y
095 Page (%): Development Unit: Bk
096 Page (%): Development Unit: C
097 Page (%): Development Unit: M
098 Page (%): Development Unit: Y
099 Page (%): Developer: Bk
100 Page (%): Developer: C
SM Appendix
*ENG [0 to 255 / - / 1 %/step]
*ENG [0 to 255 / - / 1 %/step]
9-263
System Service Mode
D037/D038/D040/D041
